Mixers

The InterFET mixer table provides the capability to sort on any JFET parameter. It is easy to find a part optimized for your application.

InterFET offers the widest range of JFET products in the industry. The InterFET portfolio is suited to meet circuit requirements for instrumentation, medical, audio, automotive, military, space, and any high precision sensor interface. Our primary expertise is in design, manufacturing, and providing innovative and practical solutions to customer problems.

PRODUCT	PACKAGE	BVgss (min) V	Vgso (min) V	Vgso (max) V	Idss (min) mA	Idss (max) mA	Gm (min) mS	ēn (typ) ɳV√Hz	Ciss (max) pF	TYPE	CONFIG	ORDERING
PRODUCT	PACKAGE	BVgss (min) V	Vgso (min) V	Vgso (max) V	Idss (min) mA	Idss (max) mA	Gm (min) mS	ēn (typ) ɳV√Hz	Ciss (max) pF	TYPE	CONFIG	ORDERING
2N4220	TO-72	-30		-4.00	0.50	3.00	1.00	6.00	6.00	N-CH	SINGLE	Mouser
2N4220A	TO-72	-30		-4.00	0.50	3.00	1.00	6.00	6.00	N-CH	SINGLE	Mouser
2N4221	TO-72	-30		-6.00	2.00	6.00	2.00	6.00	6.00	N-CH	SINGLE	Mouser
2N4221A	TO-72	-30		-6.00	2.00	6.00	2.00	6.00	6.00	N-CH	SINGLE	Mouser
2N4222	TO-72	-30		-8.00	5.00	15.00	2.50	7.00	6.00	N-CH	SINGLE	Mouser
2N4222A	TO-72	-30		-8.00	5.00	15.00	2.50	7.00	6.00	N-CH	SINGLE	Mouser
2N4416	TO-72	-30	-1.00	-6.00	5.00	15.00	4.50	4.00	4.00	N-CH	SINGLE	Mouser
2N4416A	TO-72	-35	-2.50	-6.00	5.00	15.00	4.50	4.00	4.00	N-CH	SINGLE	Mouser
2N5397	TO-72	-25	-1.00	-6.00	10.00	30.00	5.50	2.50	5.00	N-CH	SINGLE	Mouser
2N5398	TO-72	-25	-1.00	-6.00	5.00	40.00	5.00	2.50	5.50	N-CH	SINGLE	Mouser
2N5484	TO-92	-25	-0.30	-3.00	1.00	5.00	3.00	4.00	5.00	N-CH	SINGLE	Direct
2N5485	TO-92	-25	-0.50	-4.00	4.00	10.00	3.50	4.00	5.00	N-CH	SINGLE	Direct
2N5486	TO-92	-25	-2.00	-6.00	8.00	20.00	4.00	4.00	5.00	N-CH	SINGLE	Direct
J304	TO-92	-30	-2.00	-6.00	5.00	15.00	4.50	4.00	3.00	N-CH	SINGLE	Mouser
J305	TO-92	-30	-0.50	-3.00	1.00	8.00	3.00	4.00	3.00	N-CH	SINGLE	Mouser
PN4220	TO-92	-30		-4.00	0.50	3.00	1.00	6.00	6.00	N-CH	SINGLE	Direct
PN4220A	TO-92	-30		-4.00	0.50	3.00	1.00	6.00	6.00	N-CH	SINGLE	Direct
PN4221	TO-92	-30		-6.00	2.00	6.00	2.00	6.00	6.00	N-CH	SINGLE	Direct
PN4221A	TO-92	-30		-6.00	2.00	6.00	2.00	6.00	6.00	N-CH	SINGLE	Direct
PN4222	TO-92	-30		-8.00	5.00	15.00	2.50	7.00	6.00	N-CH	SINGLE	Direct
PN4222A	TO-92	-30		-8.00	5.00	15.00	2.50	7.00	6.00	N-CH	SINGLE	Direct
PN4416	TO-92	-30	-1.00	-6.00	5.00	15.00	4.50	4.00	4.00	N-CH	SINGLE	Direct
PN4416A	TO-92	-35	-2.50	-6.00	5.00	15.00	4.50	4.00	4.00	N-CH	SINGLE	Direct
PN5397	TO-92	-25	-1.00	-6.00	10.00	30.00	5.50	2.50	5.00	N-CH	SINGLE	Direct
PN5398	TO-92	-25	-1.00	-6.00	5.00	40.00	5.00	2.50	5.50	N-CH	SINGLE	Direct
SMP4220	SOT-23	-30		-4.00	0.50	3.00	1.00	6.00	6.00	N-CH	SINGLE	Mouser
SMP4220A	SOT-23	-30		-4.00	0.50	3.00	1.00	6.00	6.00	N-CH	SINGLE	Direct
SMP4221	SOT-23	-30		-6.00	2.00	6.00	2.00	6.00	6.00	N-CH	SINGLE	Mouser
SMP4221A	SOT-23	-30		-6.00	2.00	6.00	2.00	6.00	6.00	N-CH	SINGLE	Direct
SMP4222	SOT-23	-30		-8.00	5.00	15.00	2.50	7.00	6.00	N-CH	SINGLE	Mouser
SMP4222A	SOT-23	-30		-8.00	5.00	15.00	2.50	7.00	6.00	N-CH	SINGLE	Direct
SMP4416	SOT-23	-30	-1.00	-6.00	5.00	15.00	4.50	4.00	4.00	N-CH	SINGLE	Mouser
SMP4416A	SOT-23	-35	-2.50	-6.00	5.00	15.00	4.50	4.00	4.00	N-CH	SINGLE	Mouser
SMP5397	SOT-23	-25	-1.00	-6.00	10.00	30.00	5.50	2.50	5.00	N-CH	SINGLE	Mouser
SMP5398	SOT-23	-25	-1.00	-6.00	5.00	40.00	5.00	2.50	5.50	N-CH	SINGLE	Mouser
SMP5484	SOT-23	-25	-0.30	-3.00	1.00	5.00	3.00	4.00	5.00	N-CH	SINGLE	Mouser
SMP5485	SOT-23	-25	-0.50	-4.00	4.00	10.00	3.50	4.00	5.00	N-CH	SINGLE	Mouser
SMP5486	SOT-23	-25	-2.00	-6.00	8.00	20.00	4.00	4.00	5.00	N-CH	SINGLE	Mouser
SMPJ304	SOT-23	-30	-2.00	-6.00	5.00	15.00	4.50	4.00	3.00	N-CH	SINGLE	Mouser
SMPJ305	SOT-23	-30	-0.50	-3.00	1.00	8.00	3.00	4.00	3.00	N-CH	SINGLE	Mouser
